FinFET
The industry’s most complete FinFET solution
With over 3 million wafers shipped since 2015, our FinFET platform is production-proven across consumer and industrial applications as the world’s most complete and competitive FinFET solution.
-
Auto Grade 1 qualification
Up to 150°C for industry-grade reliability
-
Single-fin libraries
For simpler, smaller, low-leakage and reliable I/Os
-
Next-level 12nm PPA
Corner tightening across our digital platform enables up to 7–8% total power reduction, 3% performance gain and 20% leakage reduction (vs 2025 benchmarks)
-
Up to 30% area compaction
Versus 22nm planar and 7.5T best-in-class power, performance and area (PPA) for high-performance and reduced area
-
Radiation resilience by design
3D architecture enables improved total ionizing dose (TID) resilience and reduced soft-error rates, supporting reliable operation in harsh environments
-
RF optimized for <15GHz applications
With RF enhancements in pipeline
-
Production-proven single-fin
Optimized for lower power usage
-
Capacitance density up to 43 fF/µm
Enabling compact, high-performance on-chip capacitors
Comprehensive, customizable enhancements for your needs
We offer next-level customization capabilities with application-focused feature enhancements. Whether you need higher drive or lower power, we enable you to build on our FinFET process technology for a solution that fits your application needs.
Our AutoPro 150 FinFET solutions are optimized for demanding, next-generation automotive applications with improved PPA (vs industry 16nm automotive solutions) and Auto Grade 1 qualification (up to 150°C) for reliable, long-term operation.
Our RF enhancement delivers significant power reductions and area scaling (vs 22nm solutions), RF devices for integrated power amplifiers (PAs) and superior RF/analog performance.
Our ULL enhancement offers improved energy efficiency with logic and SRAM power reduction, enabling longer battery life and lower standby power through a new ultra-high threshold voltage (UHVT) device for 10x reduction (<0.5pA/cell) and SRAM UHVT Iret for 30x reduction.
Frequently asked questions (FAQs)
Our FinFET process technologies support Auto Grade 1 designs with a broad ecosystem of proven IPs tailored to automotive applications, including logic, memory, interface and analog IP to enable safety-critical applications.
Our FinFET’s RF-optimized architecture delivers high performance, power efficiency and area scaling for RF designs, supporting today’s advanced wireless applications.
Our FinFET process technologies are manufactured at our accredited Malta, New York facility, delivering a secure and trusted solution aligned with U.S. regulatory requirements.
