Process design kits
Our process design kits (PDKs) are the foundation for successful IC design. Built for our differentiated technology platforms, GF PDKs help you achieve first-pass silicon success, reducing risk, accelerating time-to-market and enabling innovation at scale.
Accurate designs start with GF PDKs
Our PDKs are the essential bridge between your designs and GF technologies. PDKs provide models, rules and libraries that describe the details of a semiconductor process to EDA tools, ensuring your design meets power, performance and area (PPA) targets while minimizing costly iterations.
-
Accuracy
Silicon-proven models for analog, RF, and digital designs
-
Efficiency
Streamlined kits for faster design cycles
-
Confidence
Built-in checks for reliability and compliance
Our PDKs at-a-glance
Our PDKs are more than design kits, they are enablers of innovation. With our global ecosystem of EDA partners, silicon-proven IP and dedicated design enablement teams, we help you move from concept to tapeout faster and with confidence.
-
Silicon-proven accuracy
Verified models for analog, RF, silicon photonics and digital designs
-
Scalability & flexibility
Hundreds of gigabytes streamlined into interactive, easy-to-use kits
-
Cross-platform consistency
Support for all major EDA flows
-
Advanced reliability checks
Built-in design rule checks (DRC), layout vs. schematic (LVS) and ESD compliance
-
Reference flows & IP integration
Silicon-validated flows and IP libraries to accelerate design time
-
Complete signoff
End-to-end PDK enablement to take designs from concept to manufacturing
Get started with GF PDKs
Access our PDKs through GF Connect, your gateway to design resources, MPW schedules and expert support.
